Ultraflex Front Mount Helm Pumps – 83933

Ultraflex UP33F Front Mount 33cc Available in four different displacement sizes. Compact design. Ball bearing piston race. Built-in lock valve for positive rudder lock. Integral relief valve for over-pressure protection. 3/4″ tapered stainless steel shaft. Easily accessible lock valve and shaft seal for replacement. Cast iron rotor for greater durability and longer life. 1/4″ NPT fitting for 3/8″ tube. Includes elbow fittings. PART NO. 83933 WEIGHT: 5kg Relief Valve Setting: 70Bar – 1000PSI No. of Pistons: 7 Model: UP33F Displacement / Revolution: 33cc – 2.0cu.in Max Wheel Diameter: 710mm Note: X64 – 83949 square flange or X57 – 83954 round flange allows the helm pumps to be installed in an intermediate dashboard position.Part numberDescriptionWeightModelSAW-83933Ultraflex UP33F Front Mount 33cc5kgUP33F
