SeaStar Solutions Dual Station Selector Unit

SeaStar Solutions Station Selector UnitWhen using dual function controls in dual station applications, it is necessary to isolate the two systems by the use of dual station exchangers, as it is not possible to back drive dual function controls. The system utilises a dual station unit for each engine function e.g. throttle and gear shift. Suitable for inboards with hydraulic gearboxes, inboards with light duty mechanical gearboxes, stern drives and outboards.Function:To be used with dual function, single lever controls to allow operation of both gear and throttle from two separate locationsMounted close to main stationFeatures:Unique lock out mechanism allows the skipper to isolate the unattended controlCables: CCX632 and CCX633 cables recommended. Also accepts universal 30/33 series cables, CC230, CC330 and CC332.Materials: Manufactured from passivated steel.Part NumberNumber of units Single Engine InstallationRequired for Twin Engine InstallationBLA-30681811Cable Application ChartNumber of units Single Engine InstallationRequired for Twin Engine InstallationControl head to dual station exchanger48Dual station unit to throttle & gearbox24Station selector to dual station unit12
