Raymarine RNS-5 5 Port Raynet Network Switch

Raymarine RNS-5 5 Port Raynet Network Switch | A80731The RNS-5 network switch is designed for expanding Raymarine integrated chartplotter systems using RayNet high-speed Ethernet cabling. Use the RNS-5 to integrate Axiom displays with radars, sonar modules, IP cameras, and Teledyne FLIR thermal cameras. The RNS-5 also supports networking with Raymarine YachtSense digital control systems and the YachtSense Link marine mobile router. Two RNS-5 switches can be daisy-chained together for larger systems. The RNS-5 is simple to install and requires no complicated setup.Key Features 5 RayNet Ethernet gigabit ports for fast and reliable connectivity Rugged IPx-6/IPx-7 construction Reliable, waterproof RayNet connector Ethernet cable ports Designed for simple bulkhead mounting LED power and network port status indicators Unmanaged- simply plug and play with Raymarine devices. No complicated setup or configurationSpecifications: Nominal supply voltage: 12 or 24 V dc Operating voltage range: 9 to 32 V dc Power Consumption: <2.5 watts <600mA @12V Operating temperature range: -25C (-13F) to + 55C (131F) Storage temperature range: -30C (22F) to + 70C (158F) Humidity: up to 93% @ 40C (104F) Water ingress protection: IPx-6/IPx-7 Dimensions (w x h x d): 286 mm (11.26 in) x 69 mm (2.72 in) x 55 mm (2.17 in) Weight : 0.36 Kg (0.79 lbs) Protocals: RayNet Ethernet. Legacy SeaTalkHS using an adaptor cable Connection Speed: 1 Gigabit Number of Ports: 5 POE (Power over Ethernet): NoMANUALS AND GUIDES
