Plastimo 59031 – Active-XS Reflector
The Plastimo 59031 Active-XS Reflector enhances radar signal reception by amplifying and re-transmitting incoming signals. This amplification significantly extends detection range and minimizes collision risks.
- Reception frequency:
- X-band radar: 9.32 – 9.5 GHz
- S-band: 2.9 – 3.1 GHz
- Operating temperature: -20° to +60° C
- Position accuracy: 1 m
- Voltage: 12 V DC, protected against current surges
- Antenna dimensions: 685 mm x 40.5 mm
- Antenna weight (without cable): 509 g
- Control box dimensions: 92 x 51 x 38 mm (L x h x d)
- Connection cable length: 24 m
- Fuse: 0.5 A, accessible from outside
- Stand-by current consumption: <23 mA
- Transmitting current consumption:
- X band: 190 mA
- S band: 155 mA
- Power: 1 W
- Standard compliant: Exceeds ISO 8729-2
- Dimensions: 92 x 51 x 38 mm (Width x Height x Depth)
