Osculati Oval Boat Handrail with External Screw Mounting – 316 Stainless Steel, 19×25 mm
The Osculati oval boat handrail is manufactured from mirror-polished 316 stainless steel and features a 19×25 mm oval section. It is designed with external screw mounting plates, providing accessible fastening points for installation.
The handrail is available in six sizes, with mounting length (L) from 219 to 915 mm and overall length (L+A) from 251 to 947 mm. Depending on the selected size, the handrail is equipped with two or three fixing plates.
Key Features
- Mirror-polished 316 stainless steel construction
- Oval section: 19×25 mm
- External screw mounting
- 2 or 3 fixing plates depending on version
- Mounting length (L): 219 to 915 mm
- Overall dimension (L+A): 251 to 947 mm
- Available heights: 55, 56 and 65 mm
Available Versions
| Article No. | Length (L) | Overall Length (L+A) | Height | Fixing Plates |
|---|---|---|---|---|
| 41.911.09 | 219 mm | 251 mm | 56 mm | 2 |
| 41.911.12 | 305 mm | 337 mm | 55 mm | 2 |
| 41.911.18 | 450 mm | 482 mm | 65 mm | 2 |
| 41.911.24 | 600 mm | 632 mm | 65 mm | 2 |
| 41.911.30 | 750 mm | 782 mm | 65 mm | 3 |
| 41.911.36 | 915 mm | 947 mm | 65 mm | 3 |
Technical Specifications
| Material | 316 stainless steel |
|---|---|
| Finish | Mirror-polished |
| Section | Oval, 19×25 mm |
| Mounting | External screw mounting |
| Fixing Plates | 2 or 3 depending on version |
