Osculati 51.656.02 – Galvanized Anti-Vibration Engine Mount M10, 200 kg Static Load

Osculati 51.656.02 – Galvanised Steel Anti-vibration Support 200 kg

The Osculati 51.656.02 Galvanised Steel Anti-vibration Support is crafted with high-quality NBR rubber with a shore hardness of 55 +/- 3. Featuring a female hole design, it is available in both galvanized steel and stainless steel variants for added durability. The galvanized steel variant has the following specifications:

• Outer Diameter (Ø A): 62 mm
• Inner Diameter (Ø E): 25 mm
• Mounting Hole Diameter (Ø D): 8.2 mm
• Height (Ø H): 30 mm
• Base Diameter (Ø K): 78 mm
• Overall Length (Ø L): 100 mm
• Thickness (S): 2 mm
• Stud Diameter (Ø G): 10 mm (MA)
• Max Static Nominal Load: 200 kg
• Studs*: 10×80 mm (Code: 51.657.10)

Designed to provide excellent vibration isolation, this support is a reliable solution for applications requiring a maximum static nominal load of 200 kg. Whether in galvanized steel or stainless steel, it ensures robust performance in various installations.
