Flexofold Bladeset FP-2B 12×10 RH
The Flexofold FP-2B 12×10 RH bladeset is designed for compact propulsion systems requiring efficient thrust and precise shaft fit. With a Developed Area Ratio of 0.83 and right-hand rotation, it delivers smooth and reliable performance. The Nickel Aluminum Bronze construction ensures durability and corrosion resistance.
Key Features
- Developed Area Ratio 0.83
- Right-hand rotation
- Precise shaft and keyway dimensions
- Nickel Aluminum Bronze material
Technical Data
| Product Diameter | 12 inch / 305 mm |
| Pitch | 10 inch |
| Number of Blades | 2 |
| Shaft Diameter | 30 mm |
| Maximum Shaft Hole Diameter | 35 mm |
| Keyway Width | 4 mm |
| Keyway Length | 8 mm |
| Taper | 1 : 10 |
| Rotation Direction | Turning right |
Brand: Flexofold (Article code: SP7851210) Barcode: 8720193082981
