Allpa Flexible Anti Vibration Mount ‘Large’, 45° Shore, Pin M20, Dims. 228x112x68mm, Max. 350kg
This robust anti-vibration mount from Allpa is ideal for engine setups up to 257kW (350hp), offering 45° Shore hardness and high load-bearing capacity. Engineered to minimize vibrations with a deflection of 5.4mm.
- Article number: 9063345/S
- EAN number: 8719182438410
- Suitable for engines up to: 257kW (350hp)
- Shore hardness: 45°
- Deflection: 5.4mm
- Maximum load per mount: 350kg
- Pin: M20
- Weight: 2.25kg
- Dimensions: A 228mm, B 68mm, C 112mm, D 182mm, F 34mm, G 18mm, J 26mm, JM M20
